INCH-POUND
MIL-DTL-17901C(SH)
10 May 2005
SUPERSEDING
MIL-B-17901B(SH)
AMENDMENT 3
12 December 1990
DETAIL SPECIFICATION
BEARING COMPONENTS, BONDED SYNTHETIC RUBBER,
WATER LUBRICATED
This specification is approved for use by the Naval Sea Systems Command, Department of the Navy, and is
available for use by all Departments and Agencies of the Department of Defense.
1. SCOPE
1.1 Scope. This specification covers stave shaped and cylindrical shaped bearings that have synthetic rubber
facings.
1.2 Classification. Bearings are of the following classes, as specified (see 6.2):
1.2.1 Classes.
(Note: Class I replaced with class III).
Class II - Cylindrical bearing, with cylindrical shaped metal backing and internally molded rubber stave
forms.
Class III - Stave bearing, nonmetallic backed.
Class IV - Cylindrical bearings, with cylindrical shaped nonmetallic backing and internally molded rubber
stave forms.
Class V - Partial-arc bearing consisting of nonmetallic half cylinders with internally bonded rubber.
2. APPLICABLE DOCUMENTS
2.1 General. The documents listed in this section are specified in sections 3, 4, or 5 of this specification. This
section does not include documents cited in other sections of this specification or recommended for additional
information or as examples. While every effort has been made to ensure the completeness of this list, document
users are cautioned that they must meet all specified requirements of documents cited in sections 3, 4, or 5 of this
specification, whether or not they are listed.
2.2 Government documents.
2.2.1 Specifications, standards, and handbooks. The following specifications, standards, and handbooks form a
part of this document to the extent specified herein. Unless otherwise specified, the issues of these documents are
those cited in the solicitation or contract.
FEDERAL SPECIFICATIONS
QQ-B-639
-
Brass, Naval: Flat Products (Plate, Bar, Sheet, and Strip)
Comments, suggestions, or questions on this document should be addressed to: Commander, Naval Sea Systems
Command, ATTN: SEA 05Q, 1333 Isaac Hull Avenue, SE, Stop 5160, Washington Navy Yard DC 20376-5160 or
emailed to commandstandards@navsea.navy.mil, with the subject line "Document Comment". Since contact
information can change, you may want to verify the currency of this address information using the ASSIST Online
database at https://assist.daps.dla.mil
AMSC N/A
FSC 3130
