MIL-DTL-17901C(SH)
TABLE V. Summary of conformance testing for staves and bearings (class II, III, IV, and V).
Requirements
No. of test
Property
Testing paragraph
Remarks
paragraph
specimens
Visual inspection
4.5.1
4.5.1
3
Dimensional
4.5.2
4.5.2
3
inspection
4.6.1/
See Table II
3
Hardness
ASTM D2240
No aging of classes
III, IV, and V; No
3.4.1
See Table IV
Adhesion
4.6.5
adhesion of class II
4.4.6/
Class V only
See Table II
5
Flexural modulus
ASTM D790
4.4 Selection of sample bearings and preparation of test specimens.
4.4.1 Statistical selection of samples. Whenever a visual, and dimensional, and hardness examination of a lot
of bearings/staves is required, the sample shall be obtained by statistical sampling. Bearings/staves shall be selected
from each lot in accordance with Table VI. The bearings shall be visually inspected (see 4.5.1), dimensionally
inspected (see 4.5.2), and hardness tested (see 4.6.1) to verify compliance with this specification.
TABLE VI. Sampling for visual, dimensional, and hardness testing.
Lot size number of bearings
Sample size number to be inspected
7
15 and under
10
16 to 40
15
41 to 110
111 to 300
25
301 to 500
35
501 to 800
50
801 to 1300
75
1301 and over
110
NOTE: Unless otherwise specified (see 6.2), any bearing/stave in the sample
containing one or more visual, dimensional, or hardness defect shall be
rejected and 100% inspection of all bearings/staves for that particular test is
mandated.
9
